Massey Ferguson 860 / 865 Combine Parts Manual (S/N: 1746-019-115 and up)

Original Factory Parts Manual for the Massey Ferguson 860 / 865 Combine.

It contains a complete list of parts for your machine it is also an excellent source of information for reassembling your machine.

This Parts Catalog outlines EVERY part on your Massey Ferguson 860 / 865 Combine.
Complete with exploded views, diagrams, part numbers, and part descriptions.

– There are parts grouped according to the location on the machine.

– Each group shows an exploded view which clearly illustrates each part in its correct relation to other parts in the illustration.

– You need a parts catalog, it saves you time, money and helps you be more informed when ordering parts.

Models Covered:
Massey Ferguson 860 Combine
Massey Ferguson 865 Combine

CONTENTS AS FOLLOWS:
PADDLE ELEVATOR TO TABLE DRIVE
PADDLE ELEVATOR SHAFTS AND DRIVES
PADDLE ELEVATOR, TABLE TO CYLINDER
PADDLE ELEVATOR EXTENSION AND DRIVE (MF860/865)
PADDLE ELEVATOR EXTENSION AND DRIVE (MF860E/865E W/ DRONNINGBORG HEADER)
SLAT ELEVATOR AND EXTENSION (WITH 3 ROW CONVEYOR) (GR/RICE RUB, RICE TRK.)
SLAT ELEVATOR AND EXTENSION (WITH 2 ROW CONVEYOR, CALIFORNIA SPECIAL ONLY)
SLAT ELEVATOR TOP SHAFT AND DRIVE (ELEVATOR WITH 3 ROW CONVEYOR)
SLAT ELEVATOR TOP SHAFT AND DRIVE (WITH 2 ROW CONVEYOR, CALIFORNIA SPECIAL ONLY)
ELEVATOR CLUTCH (ELECTROMAGNETIC THROW-OUT)
ELEVATOR DRIVE SHIELDS (RUB, TRK.)
CYLINDER HOUSING
CYLINDER DRIVE (ELECTRIC VARIABLE SPEED)
CYLINDER DRIVE
ELECTRIC ACTUATOR
CYLINDER RASP BAR (HIGH INERTIA, 860/865 COMBINE)
CYLINDER RASP BAR (HIGH INERTIA, 860E/865E COMBINE)
CYLINDER (SPIKE TOOTH)
CONCAVE (RASP BAR)
CONCAVE (SPIKED TOOTH)
CONVERSION (RASP BAR CYLINDER TO SPIKE TOOTH)
CONVERSION (SPIKE TOOTH CYLINDER TO RASP BAR)
CONCAVE CONTROL
STONE TRAP, FEED PLATE
FRONT BEATER
REAR BEATER
WALKER BODY
STRAW WALKERS (860, 860E, 865, 865E)
STRAW WALKER PAN (860, 860E, 865, AND 865E)
STRAW WALKER AND RETURNS ELEVATOR DRIVE
GRAIN PAN AND SHAKER SHAFT
FANNING MILL
SHAKER SHOE AND SIEVES
SHAKER SHOE CONVERSION
SHAKER SHOE CONVERSION
SCREENS AND SIEVES
REAR HOOD, CURTAIN AND DEFLECTOR (MF 860 AND 860E)
REAR HOOD, CURTAIN AND DEFLECTOR (MF 865 AND 865E)
CASCADE SEPARATOR (SHEET METAL)
CASCADE SEPARATOR (UPPER AND LOWER AUGERS)
CASCADE SEPARATOR
CASCADE SEPARATOR (ELEVATOR HOUSING)
CASCADE SEPARATOR (CYLINDER)
CASCADE SEPARATOR (HARNESS AND SENSORS)
STRAW SPREADER (MF 860 COMBINE)
STRAW SPREADER DRIVE (MF 860 COMBINE)
STRAW SPREADER (MF 865 AND 865E)
STRAW SPREADER (MF 865 AND 865E)
STRAW CHOPPER DRIVE (GRAIN, RICE AND SOYBEAN) (860, 860E, 865, 865E)
STRAW CHOPPER DRIVE (CORN) (860, 865)
STRAW CHOPPER
STRAW CHOPPER SHIELD AND CURTAIN
LEFT HAND DRIVE
LEFT HAND DRIVE IDLERS (FANNING MILL)
GRAIN TANK
GRAIN TANK EXTENSION
GRAIN ELEVATOR
GRAIN ELEVATOR DRIVE
GRAIN TANK UNLOADER BOTTOM
GRAIN TANK UNLOADER TOP
GRAIN TANK UNLOADER DRIVE
RETURNS ELEVATOR
RETURNS ELEVATOR CARRIERS
LEFT SIDE SHIELDS (RUBBER, TRACK)
RIGHT SIDE SHIELDS (860, 860E, 865, 865E)
MAIN FRAME
FRONT AXLE, SHAFTS AND COUPLINGS (4-SPEED TRANSMISSION)
FRONT AXLE, SHAFTS AND COUPLINGS (HYDROSTATIC TRANSMISSION) (GR/RICE RUBBER, RICE TRACK)
FRONT WHEELS (GRAIN, RICE)
MAIN DRIVE CONTROL
TRACTION DRIVE (HYDROSTATIC TRANSMISSION)
VARIABLE SPEED TRACTION DRIVE (4 SPEED TRANSMISSION)
TRACTION CLUTCH (4 SPEED TRANSMISSION)
GEAR SHIFT (4 SPEED TRANSMISSION)
GEAR SHIFT (HYDROSTATIC TRANSMISSION)
STEERING PEDESTAL
STEERING WHEEL COLUMN AND CONTROL UNIT
TRANSMISSION (4 SPEED WITH 2 PINION PLANETARY)
CONSTANT MESH TRANSMISSION (HYDROSTATIC, NORTH AMERICA ONLY)
CONSTANT MESH TRANSMISSION (HYDROSTATIC, EUROPE ONLY)
HYDROSTATIC CONTROLS
HYDROSTATIC PRESSURE RELEASE CONTROLS
HYDROSTATIC PUMP DRIVE AND MOTOR (SUNSTRAND PUMP AND MOTOR)
HYDROSTATIC PUMP (SUNSTRAND)
PUMP DRIVE MOTOR (SUNSTRAND)
HYDROSTATIC COOLING SYSTEM
OIL COOLER FAN AND DRIVE
FINAL DRIVE (RUBBER RIGHT, RUBBER LEFT) (TRACK RIGHT, TRACK LFET)
PARKING BRAKE CONTROLS (N.A. OR EUR.)
TURNING BRAKES
BRAKE CYLINDER, BRAKE ASSEMBLY
TRACK, FRAME AND AXLE (RICE RIGHT, TRACK LEFT)
TRACK, IDLER AND ROLLERS (RICE LEFT, TRACK RIGHT)
“A” FRAME AND REAR WHEELS
FIXED REAR AXLE
ADJUSTABLE REAR AXLE
REAR WHEEL DRIVE ADJUSTABLE AXLE
REAR WHEEL DRIVE HYDRAULICS
HYDRAULIC MOTOR
PLANETARY GEAR BOX
SELECTOR VALVE
OPERATOR’S PLATFORM AND LADDER
CONTROL BOX (4 SPEED, HYDRO. STAT)
ELECTRICAL HARNESS (COMBINE) (860, 865) (860E, 865E)
HARNESS AND SWITCHES (CONTROL CONSOLE) (860, 865, 860E, 865E)
HARNESS, INSTRUMENTS AND SWITCHES (CAB)
GRAIN LOSS MONITOR
ENGINE AND BATTERY WIRING (AT6-354.4CC)
ENGINE AND BATTERY WIRING (AV8-540 DIESEL)
ALTERNATOR
STARTER (AT6-354.4CC)
SOLENOID (AT6 – 354.4CC)
STARTER (AT6 – 354.4CC)
SOLENOID (AT6 – 354.4CC)
STARTER AND SOLENOID (AV8-540 DIESEL)
SOLENOID (AV8 – 540 DIESEL)
STARTER AND SOLENOID (AV8 – 540 DIESEL)
SOLENOID (AV8 – 540 DIESEL)
LIGHTING
LIGHTING (ROAD LIGHTS, EUROPE ONLY)
FLOODLIGHTS
LIGHTS
TAIL LIGHT AND WARNING LAMP
ELECTRIC ETHER STARTING KIT
SEAT (VICTOR)
SEAT (SEARS)
ENGINE COVER
ENGINE COVER EXTENSION
ROTARY AIR INTAKE AND DRIVE (WITH CHAFF EXTRACTOR)
FUEL TANK, LINES, SUPPORTS AND TOOL BOX (6 CYL. ENGINE, 8 CYL. ENGINE)
HYDRAULIC CONTROLS (4) OR (HYDRO.)
MAIN HYDRAULIC CONTROL VALVE (3 SPOOL)
HYDROSTATIC REEL DRIVE
HYDRAULIC PRESSURE AND RETURN LINES (STD. TRAN.) (HYD. TRAN.)
HYDRAULIC PUMP
CONTROL VALVE (TABLE HEIGHT)
CONTROL VALVE (TABLE HEIGHT, REEL FORE AND AFT)
HYDRAULIC TANK (STD. W/RL DRIVE) (HYD. W/RL DRIVE) (HYD. W/O RL DRIVE)
REEL LIFT HYDRAULICS
HYDRAULIC CONTROL REEL FORE AND AFT (FLOTATION ACCUMULATOR, EUROPE ONLY)
TABLE LIFT HYDRAULICS
TABLE LIFT CYLINDER (GR/RICE RUB.) (RICE TRK.)
FLOATATION ACCUMULATOR (.7 LITER ACCUMULATOR)
TANK UNLOADER CONTROLS
TANK UNLOADER HYDRAULICS
UNLOADER CYLINDER
VARIABLE SPEED HYDRAULICS (4 SPEED)
VARIABLE SPEED CYLINDER
STEERING HYDRAULICS (MF 860 AND MF 865)
STEERING HYDRAULICS (MF 860E AND 865E)
STEERING CYLINDER
RELIEF VALVE
HYDRAULIC PUMP DRIVE AND ENGINE SUPPORTS
GREASE HARNESS
REAR MOTOR HOUSING
BELTS
CHAINS (PADDLE ELEVATOR)
CHAINS (PADDLE ELEVATOR) (CONVERSION FROM RUBBER TO TRACK)
CHAINS (SLAT ELEVATOR) (W/O EXT., WITH EXT.)
CHAINS
CONVEYOR CHAIN
ADAPTING PART FOR CORN HEAD (RIGHT HAND DRIVE)
EMBLEMS AND LABELS
EMBLEMS AND LABELS (FRENCH)
ACCESSORIES (POLYURETHANE PAINT)
CYLINDER BLOCK (AT6-354,4CC)
CRANKSHAFT, FLYWHEEL, INSERTS (AT6-354, 4CC)
PISTONS, RINGS AND RODS
TIMING GEAR AND CAMSHAFT (AT6-354, 4CC)
CYLINDER HEAD COVER (AT6-354, 4CC)
CYLINDER HEAD (AT6-354, 4CC AND AT6-354, 4 DIESEL)
OIL PAN, FILTER AND PUMP (AT6-354, 4CC AND AT6-354, 4 DIESEL)
OIL COOLER AND FILTER (AT6-354, 4CC)
GASKET SETS (AT6-354, 4CC DIESEL)
WATER PUMP AND ATTACHING PARTS (AT6-354, 4CC)
MANIFOLDS AND TURBOCHARGER (AT6-354, 4CC)
INJECTION SYSTEM (AT6-354, 4CC)
INJECTION PUMP AND INJECTOR
TURBOCHARGER (AT6-354, 4CC)
FUEL FILTERS AND LINES (AT6-354, 4CC)
LIFT PUMP AND FUEL FILTER (AT6-354, 4CC)
RADIATOR AND HOSES (AT6-354, 4CC)
AIR INTAKE AND EXHAUST (AT6-354, 4CC DIESEL, USED COMB. SER. NO.1746019942 AND UP)
AIR INTAKE AND EXHAUST (AT6-354, 4CC, USED PRIOR TO COMBINE SER. NO.1746019942)
THROTTLE CONTROL, FUEL SHUT-OFF (AT6-354, 4CC)
CYLINDER BLOCK (AV8-540 DIESEL)
CRANKSHAFT FLYWHEEL AND BEARINGS (AV8-540 DIESEL)
CYLINDER HEAD AND VALVES (AV8-540 DIESEL)
CYLINDER HEAD COVER AND ROCKERSHAFT (AV8-540 DIESEL)
CAMSHAFT AND TIMING GEARS (AV8-540 DIESEL)
OIL PAN, PUMP AND COOLER (AV8-540 DIESEL)
OIL PAN (AV8-540 DIESEL)
LUBRICATION OIL FILTER (AV8-540 DIESEL)
ENGINE GASKET SETS (AV8-540 DIESEL)
WATER PUMP AND IDLER PULLEY (AV8-540 DIESEL)
THROTTLE CONTROL, FUEL SHUT-OFF (AV8-540 DIESEL)
FUEL INJECTION LINES (AV8-540 DIESEL)
FUEL FILTER AND INJECTION PUMP (AV8-540 DIESEL)
AUXILIARY DRIVE (AV8-540 DIESEL)
AIR INTAKE AND EXHAUST
AIR INTAKE AND EXHAUST
INTAKE AND EXHAUST MANIFOLDS (AV8-540 DIESEL)
RADIATOR AND HOSES (AV8-540 DIESEL)
RADIATOR FAN DRIVE (AV8-540 AND AT6-354, 4CC)
CAB (SHEET METAL, WINDOWS)
CAB (SEALING AND TRIM)
CAB (SEALING AND TRIM)
COMPRESSOR AND CONDENSOR
COMPRESSOR
AIR CONDITIONING AND LINES
PRESSURIZER
HEATER
WINDSHIELD WIPER

———————-

Model Specification: Massey Ferguson 860 / 865 Combine
Serial Number: 1746-019-115 and up
Language: English
Total Pages: 474
File Format: PDF
Requirements: Adobe PDF Reader
Zoom In/Out: yes
Notes: Searchable, Fully printable, instant download
Compatible: All Versions of Windows & Mac, Linux OS, Iphone, Ipad, Smartphone, Android etc…

———————-
