Original Factory Parts Manual for the Massey Ferguson 860 Combine.
It contains a complete list of parts for your machine it is also an excellent source of information for reassembling your machine.
This Parts Catalog outlines EVERY part on your Massey Ferguson 860 Combine.
Complete with exploded views, diagrams, part numbers, and part descriptions.
– There are parts grouped according to the location on the machine.
– Each group shows an exploded view which clearly illustrates each part in its correct relation to other parts in the illustration.
– You need a parts catalog, it saves you time, money and helps you be more informed when ordering parts.
CONTENTS AS FOLLOWS:
TABLE (RIGIN CUTTER BAR) (1859 SERIES) (13, 15, 16, 18, 20′)
TABLE PLATE, SHIELDS AND DIVIDERS (RIGID CUTTER BAR) (1859 SERIES) (13, 15, 16, 18, 20′)
TABLE (FLOATING AND RIGID CUTTER BAR) (2381 SERIES) (22′, 24′, 30′)
TABLE DIVIDERS AND SHIELDS (2381 SERIES) (22 AND 24 FOOT RIGID AND FLOATING CUTTER BAR)
TABLE (FLOATING CUTTER BAR) (1859 SERIES) (15, 16′)
TABLE (FLOATING CUTTER BAR) (18, 20′)
DIVIDERS AND SHIELDS (FLOATING CUTTER BAR) (REGULAR FIXED)
FLOATING EXTENDED DIVIDERS (FLOATING CUTTER BAR)
SHIELDS AND BRACKETS (FLOATING CUTTER BAR) (15′, 16′, 18, 20′, 22′)
COUNTER BALANCE, IDLER, SPRING PIVOT ASSEMBLY (HOOP AND FLOATING DIVIDER) (15′ – 20′ FLOATING CUTTER BAR)
COUNTER BALANCE AND IDLERS (22′ FLOATING CUTTER BAR)
SPRING, PIVOT ASSEMBLY (HOOP AND FLOATING DIVIDER) (22′ FLOATING CUTTER BAR)
DRAPER TABLE
TABLE BRACES
REEL ARMS, DIVIDERS AND SHIELDS (DRAPER TABLE) (L, R)
AUGER (1859 SERIES 20 DIA.) (13, 15, 16′)
AUGER (1859 SERIES, 20 DIA.) (18, 20′)
AUGER (DRAPER TABLE) (2038 SERIES , 22′ DIA.)
AUGER (22, 24, 30′ TABLE) (2381 SERIES, 22 DIA.)
KNIFE (RIGID CUTTER BAR) (1859 SERIES) (15, 16, 18, 20′)
KNIFE (RIGID CUTTER BAR) (2381 SERIES) (22, 24, 30′)
KNIFE (FLOATING CUTTER BAR) (GRAIN AND RICE) (15, 16, 18, 20′, 22′)
CUTTER BAR (FLOATING CUTTER BAR) (GRAIN AND RICE) (15, 16, 18, 20′, 22′)
WOBBLE KNIFE DRIVE (ALL TABLES)
TABLE DRIVE (13, 15 AND 16 TABLE) (1859 SERIES) (RIGID, FLOAT)
TABLE DRIVE (18′ AND 20′ TABLE) (1859 SERIES) (RIGID, FLOAT)
DRIVES, KNIFE AND AUGER (DRAPER TABLE) (2038 SERIES)
DRIVE TABLE (22, 24, 30 TABLE) (2381 SERIES)
REEL DRIVE (BELT)
REEL DRIVE (CHAIN)
REEL DRIVE (ELECTRIC VARIABLE SPEED)
ELECTRIC VARIABLE SPEED REEL DRIVE
ELECTRIC MOTOR AND WIRING
HYDROSTATIC REEL DRIVE HYDRAULICS
HYDROSTATIC REEL DRIVE HYDRAULICS
HYDROSTATIC REEL DRIVE, LEFT SIDE (2381 SERIES) (22′ RICE TABLE)
HYDROSTATIC REEL DRIVE, RIGHT SIDE (2381 SERIES) (22, 24, 30′ TABLE)
REEL DRIVE HYDRAULICS (DRAPER TABLE) (WITH MOTORS IN PARALLEL)
REEL DRIVE HYDRAULICS (WITH MOTORS IN SERIES)
HYDRAULIC PUMP AND RESERVOIR (2381 SERIES)
HYDRAULIC MOTOR (USED W/ 1859 AND 2038 SERIES TABLES)
HYDRAULIC MOTOR (USED W/ 2381 SERIES TABLES)
REEL AND SUPPORTS (15′ THRU 20′ TABLES) (1859 SERIES TABLE)
REEL AND SUPPORTS (2381 SERIES TABLE) (22, 24, 30′)
REEL LIFT (15′ THRU 20′ TABLES) (GRAIN AND RICE)
REEL LIFT, HYDRAULICS (DRAPER TABLE)
REEL LIFT CYLINDERS (15′ THRU 20′ TABLES) (GRAIN AND RICE)
REEL LIFT HYDRAULICS (2381 SERIES) (RIGID AND FLOATING CUTTER BAR)
REELLIFT CYLINDERS (2381 TABLE SERIES)
DRAPER AND DRIVE (DRAPER TABLE) (2038 SERIES)
PICK-UP REEL (GRAIN – 6″ SPACING – 5 BAT)
PICK-UP REEL (GRAIN – 6″ SPACING – 5 BAT) – PICK-UP REEL (GRAIN – 6″ SPACING – 5 BAT)
PICK-UP REEL (GRAIN – 6″ SPACING – 6 BAT)
PICK-UP REEL (GRAIN – 6″ SPACING – 6 BAT) – PICK-UP REEL (GRAIN – 6″ SPACING – 6 BAT)
PICK-UP REEL (RICE – 4″ SPACING – 6 BAT)
PICK-UP REEL (RICE – 4″ SPACING – 6 BAT) (2759 690)
CLUTCH AND ANTI-WRAP SHIELD 5 AND 6 BAT REELS
TABLE HEIGHT CONTROL (RIGID CUTTER BAR) (1859 SERIES TABLE)
TABLE HEIGHT CONTROL (RIGID CUTTER BAR) (15, 16, 18, 20′)
TABLE HEIGHT CONTROL (2381 SERIES) (22′ RIGID AND FLOATING CUTTER BAR)
TABLE HEIGHT CONTROL (FLOATING CUTTER BAR)
TABLE HEIGHT CONTROL (FLOATING CUTTER BAR) (15, 16, 18, 20′)
ELEVATOR TO TABLE DRIVE (PADDLE)
ELEVATOR SHAFTS AND DRIVES (PADDLE)
ELEVATOR, TABLE TO CYLINDER (PADDLE)
ELEVATOR EXTENSION AND DRIVE (PADDLE ELEVATOR)
ELEVATOR AND EXTENSION (SLAT, WITH 3 ROW CONVEYOR)
ELEVATOR AND EXTENSION (SLAT, WITH 3 ROW CONVEYOR)
ELEVATOR AND EXTENSION (SLAT, WITH 2 ROW CONVEYOR)
ELEVATOR TOP SHAFT AND DRIVE
ELEVATOR TOP SHAFT AND DRIVE
ELEVATOR TOP SHAFT AND DRIVE (SLAT ELVATOR W/2 ROW CONVEYOR) (CALIFORNIA SPECIAL ONLY)
ELEVATOR CLUTCH (ELECTRO MAGNETIC HEADER THROW-OUT) (GRAIN AND RICE)
ELEVATOR DRIVE SHIELDS (RUBBER, TRACK)
CYLINDER HOUSING
CYLINDER DRIVE (2 SPD.)
CYLINDER DRIVE (2 SPD.)
VARIABLE SPEED DRIVE CONTROL
CYLINDER, RASP BAR (HIGH INERTIA)
CYLINDER, RASP BAR (HIGH INERTIA)
CYLINDER (SPIKE TOOTH)
CONCAVE (RASP BAR) (WIDE, NARROW)
CONCAVE (SPIKED TOOTH)
CONCAVE CONTROL
CONCAVE CONTROL
STONE TRAP, FEED PLATE
FRONT BEATER (PADDLE, SLAT)
REAR BEATER
WALKER BODY
STRAW WALKERS (GRAIN, RICE)
STRAW WALKER AND RETURNS ELEVATOR DRIVE
GRAIN PAN AND SHAKER SHAFT
FANNING MILL
SHAKER SHOE AND SIEVES
SCREENS
HOOD
HOOD (EUROPE ONLY) (FOR CASCADE SEPARATOR)
STRAW SPREADER
STRAW SPREADER DRIVE
LEFT HAND DRIVE
LEFT HAND DRIVE IDLERS
GRAIN TANK
GRAIN TANK EXTENSION
GRAIN ELEVATOR
GRAIN ELEVATOR DRIVE
GRAIN TANK UNLOADER BOTTOM
GRAIN TANK UNLOADER TOP
GRAIN TANK UNLOADER DRIVE
RETURNS ELEVATOR
RETURNS ELEVATOR CARRIERS
MAIN FRAME
FRONT AXLE, SHAFTS AND COUPLINGS (4 SPEED TRANSMISSION) (GRAIN RUBBER)
FRONT AXLE, SHAFTS AND COUPLINGS (HYDROSTATIC TRANSMISSION) (GRAIN & RICE RUBBER, RICE TR.)
FRONT WHEELS (GRAIN, RICE)
MAIN DRIVE
TRACTION DRIVE (HYDROSTATIC TRANSMISSION)
VARIABLE SPEED TRACTION DRIVE (4 SPEED TRANSMISSION)
TRACTION CLUTCH (4 SPEED TRANSMISSION)
GEAR SHIFT (4 SPEED TRANSMISSION)
GEAR SHIFT (HYDROSTATIC TRANSMISSION)
TRANSMISSION (4 SPEED WITH 2 PINION PLANETARY)
CONSTANT MESH TRANSMISSION (HYDROSTATIC, NORTH AMERICA ONLY)
CONSTANT MESH TRANSMISSION (HYDROSTATIC, EUROPE ONLY)
HYDROSTATIC CONTROLS
HYDROSTATIC PRESSURE RELEASE CONTROLS
HYDROSTATIC PUMP DRIVE AND MOTOR (EATON PUMP AND MOTOR)
HYDROSTATIC PUMP DRIVE AND MOTOR (SUNDSTRAND PUMP AND MOTOR)
HYDROSTATIC PUMP (SUNDSTRAND)
HYDROSTATIC PUMP (SUNDSTRAND)
PUMP DRIVE MOTOR (SUNDSTRAND)
PUMP DRIVE MOTOR (SUNDSTRAND)
HYDROSTATIC PUMP (EATON)
HYDROSTATIC PUMP (EATON)
CONTROL VALVE, CHARGING PUMP (HYDROSTATIC PUMP) (EATON)
PUMP DRIVE MOTOR (EATON)
PUMP DRIVE MOTOR
HYDROSTATIC COOLING SYSTEM
HYDROSTATIC COOLING SYSTEM
HYDROSTATIC COOLING SYSTEM
HYDROSTATIC COOLING SYSTEM
FINAL DRIVE (USED COMBINE SERIAL NUMBER 174618278 AND UP) (RUBBER – RIGHT-LEFT, TRACK – RIGHT/LEFT)
FINAL DRIVE (USED COMBINE SERIAL NUMBER 174618278) (RUBBER – RIGHT/LEFT, TRACK – RIGHT/LEFT)
PARKING BRAKE CONTROLS (NORTH AMERICA AND EUROPE)
TURNING BRAKES
BRAKE CYLINDER, BRAKE ASSEMBLY
TRACK, FRAME AND AXLE (RICE TRACK – LEFT/RIGHT)
TRACK, IDLER AND ROLLERS (RICE TRACK – LEFT/RIGHT)
“A” FRAME AND REAR WHEELS
ADJUSTABLE REAR AXLE
REAR WHEEL DRIVE ADJUSTABLE AXLE (LATE PRODUCTION)
REAR WHEEL DRIVE HYDRAULICS (LATE PRODUCTION)
HYDRAULIC PUMP
PLANETARY GEAR BOX
SELECTOR VALVE
REAR WHEEL DRIVE, ADJUSTABLE AXLE (EARLY PRODUCTION)
REAR WHEEL DRIVE HYDRAULICS (EARLY PRODUCTION)
MOTOR ASSEMBLY (MOTOR HOUSING AND AXLE YOKE)
MOTOR ASSEMBLY (WHEEL HUB, CYLINDER HOUSING AND BLOCK)
MOTOR ASSEMBLY (WHEEL MANIFOLD)
MOTOR ASSEMBLY (PLANET PINION, CARRIER, HOUSING)
REAR WHEEL DRIVE CONTROL VALVE
REAR WHEEL DRIVE WIRING
OPERATOR’S PLATFORM AND LADDER
CONTROL BOX (4 SPEED, HYDROSTAT.)
INSTRUMENTS AND SWITCHES
MONITOR SYSTEM
BATTERY AND WIRING (AT6-3544 ENGINE)
BATTERY AND WIRING (AV8-540 ENGINE)
ALTERNATOR
STARTER (AT6-354 ENGINE)
SOLENOID (AT6-354 ENGINE)
STARTER AND SOLENOID (SEE NOTE “A”) (AV8-540 ENGINE)
STARTER AND SOLENOID (SEE NOTE “A”)
STARTER (AV8-540 ENGINE)
SOLENOID (AV8-540 ENGINE)
LIGHTING (NORTH AMERICA)
LIGHTING (ROAD LIGHTS, EUROPE ONLY)
FLOODLIGHTS
LIGHTS
TAIL LIGHT AND WARNING LAMP
ELECTIC ETHER STARTING KIT
GRAIN LOSS MONITOR
SEAT (VICTOR)
SEAT (SEARS)
STEERING PEDESTAL
STEERING PEDESTAL
STEERING WHEEL, COLUMN AND CONTROL UNIT
STEERING WHEEL, COLUMN AND CONTROL UNIT
ENGINE COVER
ENGINE COVER EXTENSION
ROTORY AIR INTAKE AND DRIVE
ROTORY AIR INTAKE AND DRIVE
FRONT SHIELDS (LEFT SIDE) (RUBBER, TRACK)
REAR SHIELDS (RIGHT SIDE)
FUEL TANK, LINES, SUPPORTS AND TOOL BOX (6 CYL, 8 CYL ENGINE)
HYDRAULIC CONTROLS (4 SPD, HYDROSTAT)
MAIN HYDRAULIC CONTROL VALVE (3 SPOOL)
HYDROSTATIC REEL DRIVE HYDRAULICS (ELECTRIC CONTROLLED)
HYDROSTATIC REEL DRIVE HYDRAULICS (MANUAL CONTROL)
HYDRAULIC PRESSURE AND RETURN LINES
HYDRAULIC PRESSURE AND REUTRN LINES
HYDRAULIC PUMP
CONTROL VALVE (TABLE HEIGHT)
CONTROL VALVE (TABLE HEIGHT, REEL FORE AND AFT) (EUROPE ONLY)
CONTROL VALVE SECTION (EUROPE ONLY)
HYDRAULIC TANK
REEL LIFT HYDRAULICS
HYDRAULIC CONTROL REEL FORE AND AFT (FLOATATION ACCUMULATOR) (EUROPE ONLY)
TABLE LIFT HYDRAULICS (GR RICE RUBBER, RICE TRACK)
FLOTATION ACCUMULATOR (COMBINES WITH AUTOMATIC HEADER HEIGHT CONTROL)
TABLE LIFT CYLINDER (GRAIN & RICE RUBBER, RICE TRACK)
TANK UNLOADER SWING CONTROLS
TANK UNLOADER HYDRAULICS
UNLOADER CYLINDER
VARIABLE SPEED HYDRAULICS (4 SPEED)
VARIABLE SPEED CYLINDER
STEERING HYDRAULICS
STEERING HYDRAULICS
STEERING HYDRAULICS (EUROPE ONLY)
STEERING CYLINDER
HYDRAULIC PUMP DRIVE AND ENGINE SUPPORTS
HYDRAULIC PUMP DRIVE AND ENGINE SUPPORTS
GREASE HARNESS
REAR MOTOR HOUSING
REAR MOTOR HOUSING
BELTS
CHAINS
CHAINS
CHAINS
CHAINS (PADDLE ELEVATOR) (CONVERSION FROM RUBBER TO TRACK)
CHAINS (SLAT ELEVATOR) (W/O EXTN, WITH EXTN.)
CONVEYOR CHAIN
ADAPTING PARTS FOR CORN HEAD (RIGHT HAND DRIVE)
EMBLEMS AND LABELS
EMBLEMS AND LABELS
CYLINDER BLOCK (AT6-3544 DIESEL)
CRANKSHAFT, FLYWHEEL, INSERTS (AT6-3544 DIESEL)
PISTONS, RINGS AND RODS (AT6-3544 DIESEL)
TIMING GEAR AND CAMSHAFT (AT6-3544 DIESEL)
CYLINDER HEAD COVER (AT6-3544 DIESEL)
CYLINDER HEAD (AT6-3544 DIESEL)
OIL PAN, FILTER AND PUMP (AT6-3544 DIESEL)
OIL COOLER AND FILTER (AT6-3544 DIESEL)
GASKET SETS (AT6-3544 DIESEL)
WATER PUMP AND ATTACHING PARTS AT6-3544 DIESEL)
MANIFOLDS (AT6-3544 DIESEL)
AIR INTAKE AND EXHAUST
AIR INTAKE AND EXHAUST
PRE-CLEANER, PRE-SCREENER
THROTTLE CONTROL, FUEL SHUT-OFF (AT6-3544 DIESEL)
INJECTION SYSTEM (AT6-3544 DIESEL)
INJECTION PUMP AND INJECTOR (AT6-3544 DIESEL)
FUEL FILTERS AND LINES (AT6-3544 DIESEL)
LIFT PUMP AND FUEL FILTER (AT6-3544 DIESEL)
TURBOCHARGER (AT6-3544 DIESEL)
RADIATOR FAN DRIVE (AT6-3544 DIESEL)
CYLINDER BLOCK (AV8-540 DIESEL)
CRANKSHAFT FLYWHEEL AND BEARINGS (AV8-540 DIESEL)
CYLINDER HEAD AND VALVES (AV8-540 DIESEL)
CYLINDER HEAD COVER AND ROCKERSHAFT (AV8-540 DIESEL)
CAMSHAFT AND TIMING GEARS (AV8-540 DIESEL)
OIL PAN, PUMP AND COOLER (AV8-540 DIESEL)
OIL PUMP (AV8-540 DIESEL)
LUBRICATION OIL FILTER (AV8-540 DIESEL)
ENGINE GASKET SETS (AV8-540 DIESEL)
WATER PUMP AND IDLER PULLEY (AV8-540 DIESEL)
THROTTLE CONTROL, FUEL SHUT-OFF (AV8-540 DIESEL)
FUEL INJECTION LINES (AV8-540 DIESEL)
FUEL FILTER AND INJECTION PUMP (AV8-540 DIESEL)
AUXILIARY DRIVE (AV8-540 DIESEL)
AIR INTAKE AND EXHAUST
AIR INTAKE
EXHAUST SYSTEM
INTAKE AND EXHAUSE MANIFOLDS (AV8-540 DIESEL)
RADIATOR, FAN, DRIVE (AV8-540 DIESEL)
STRAW CHOPPER (DRIVE ASSEMBLY)
HOUSING, ADAPTER AND ROTOR
CORN KIT (WITH SLOW DOWN SHEAVE) (1750377)
CAB (SHEET METAL, WINDOWS)
CAB (SEALING AND TRIM)
CAB (SEALING AND TRIM)
COMPRESSOR EVAPORATOR AND CONDENSER
COMPRESSOR
AIR CONDITIONING AND LINES
AIR CONDITIONING AND LINES
CAB ELECTRICAL WIRING
PRESSURIZER
HEATER (USED COMBINE SERIAL NUMBER 174615224 AND UP)
HEATER (USED PRIOR TO COMBINE SERIAL NUMBER 174615224)
WINDSHIELD WIPER (EUROPE ONLY)
ACCESSORIES (PAINT)
———————-
Model Specification: Massey Ferguson 860 Combine
Serial Number: Prior to 1746-019-115
Language: English
Total Pages: 667
File Format: PDF
Requirements: Adobe PDF Reader
Zoom In/Out: yes
Notes: Searchable, Fully printable, instant download
Compatible: All Versions of Windows & Mac, Linux OS, Iphone, Ipad, Smartphone, Android etc…
———————-
Pay Today and Download the complete manual instantly. The download link will also be sent to your e-mail. So please make sure your email address is correct. Don’t Forget to Check Spam / Junk if can’t find the new message in your email inbox immediately.
Thanks for Visiting.
